Osteo-site® Needles



Osteo-site® Needles

Ergonomic handle design of the cannula enabling positive experience and maximum performance
Radiolucent handle which provides an unobstructed view during introduction into bone, ensuring accurate needle placement
Outer cannula is marked with 1 cm increments in order to help guide and gauge depth
Outer cannula has a sharpened cutting tip to maintain access for biopsy and infusion when inner stylet is removed
The sharp diamond- tipped stylet facilitates easy placement into the periosteum and bone cortex
The 30° side-beveled stylet for minor redirection of needle during introduction
Certain sets include a 20 cm radiolucent needle-holder

Bone Access Needles


Bone Biopsy Needle Set
Side-bevel and diamond-tip


Used for vertebral body biopsy and infusion
2 inner stylets featuring 1 side-beveled and 1 diamond shaped tip
A blunt tip stainless steel obturator is included
Available in two gauges, 11 and 13
Available in two lengths, 10 cm and 15 cm
Supplied sterile in peel-open packages
Intended for one-time use only

izi osteosite bbns.png


Murphy M1M™ - Side-bevel
Bone Biopsy Needle


Used for vertebral body biopsy and infusion
Inner stylet and outer cannula are side-beveled to match
A blunt tip stainless steel obturator is included
A 20 cm long radiolucent needle holder is included
Available in two gauges, 11 and 13
Available in two lengths, 10 cm and 15 cm
Supplied sterile in peel-open packages
Intended for one-time use only

izi osteosite murphy m1m bone biopsy needle.png


Murphy M2™
Diamond-tip Bone Biopsy Needle


Used for vertebral body biopsy and infusion
Inner stylet is ground to match the trephine tip of the depth-marked outer cannula
A blunt tip stainless steel obturator is included
A 20 cm long radiolucent needle holder is included
Available in two gauges, 11 and 13
Available in two lengths, 10 cm and 15 cm
Supplied sterile in peel-open packages
Intended for one-time use only

izi osteosite murphy m2 bone biopsy needle.png


Martin Cervical Bone Biopsy Needle Set
Side-bevel and diamond-tip


Used for vertebral body biopsy and infusion
Inner stylet and depth-marked outer cannula are side-bevel
A blunt tip stainless steel obturator is included
A 20 cm long radiolucent needle holder is included
Available in 15 gauge
Available in two lengths, 10 cm and 15 cm
Supplied sterile in peel-open packages
Intended for one-time use only

izi osteosite martin cervical bbn.png


Ratchet Bone Biopsy Needle Set
Hand drilling into hard bone


Used for vertebral body biopsy and infusion
Ratchet-style unidirectional drilling action and unique spade tip design
A blunt tip stainless steel obturator is included
Available in two gauges, 11 and 13
Available in two lengths, 10 cm and 15 cm
Supplied sterile in peel-open packages
Intended for one-time use only

izi osteosite rachet bbns.png


Bone Biopsy Needles


Murphy M2-S™
Multi-Purpose Coaxial Bone Biopsy Needle Set


Used for vertebral body biopsy and infusion
Includes a high-torque steel inner biopsy needle with trephine tip
A blunt tip stainless steel obturator is included
A 20 cm long radiolucent needle holder is included
Available in two gauges, 11 and 13
Available in two lengths, 10 cm and 15 cm
Supplied sterile in peel-open packages
Intended for one-time use only

izi osteosite murphy m2s bbn.png


Coaxial Curved Bone Biopsy Needle Set
Side-bevel


Used for vertebral body biopsy and infusion
Inner stylet and depth-marked outer cannula are side-beveled to match
A curved needle with a flexible stylet are included
A blunt tip stainless steel obturator and a curved needle obturator are included
Introducer needles available in 10 gauge, 10 cm length
Curved needles available in 13 gauge, 19 cm length
Supplied sterile in peel-open packages
Intended for one-time use only

izi osteosite coaxial curved bbns.png


Coaxial Bone Biopsy Needle Set
Trephine tip


Used for the coaxial biopsy
Outer cannula features trephine tip to ease access
Compatible with any standard Osteo-Site® outer cannula size (11 or 13 gage)
A blunt tip stainless steel obturator is included
Available in two gauges, 14 and 16
Available in two lengths, 17.1 cm and 22.1 cm
Supplied sterile in peel-open packages
Intended for one-time use only

izi osteosite coaxial trephine tip bbns.png
